Ausführung

Die instanziierten Pläne werden von einer execute-Aufgabe ausgeführt. In dieser Phase gleicht der Ausführungsprozess, basierend auf den Aufgaben-Aktionsdaten, den realen Controller anhand der Wortumgebung ab und führt den Plan Schritt für Schritt aus. Nach der Ausführung bewertet der evalution-Agent die Qualität des gesamten Ausführungsprozesses.

ExecuteFlow

Die Klasse ExecuteFlow wurde entwickelt, um die Ausführung und Bewertung von Aufgaben in einer Windows-Anwendungsumgebung zu erleichtern. Sie bietet Funktionalität zur Interaktion mit der Benutzeroberfläche der Anwendung, zur Ausführung vordefinierter Aufgaben, zum Erfassen von Screenshots und zur Bewertung der Ausführungsergebnisse. Die Klasse verwaltet auch die Protokollierung und Fehlerbehandlung für die Aufgaben.

Aufgabenausführung

Die Aufgabenausführung in der Klasse ExecuteFlow folgt einer strukturierten Sequenz, um eine genaue und nachvollziehbare Aufgabenausführung zu gewährleisten.

  1. Initialisierung:

  2. Konfigurationseinstellungen und Protokollpfade laden.

  3. Das Anwendungsfenster finden, das der Aufgabe entspricht.
  4. Einen ExecuteAgent zur Ausführung der Aufgabe abrufen oder erstellen.
  5. Planausführung:

  6. Durch jeden Schritt im instantiated_plan iterieren.

  7. Den Schritt parsen, um Informationen wie Unteraufgaben, Steuerelementtext und die erforderliche Operation zu extrahieren.
  8. Aktionsausführung:

  9. Das Steuerelement im Anwendungsfenster finden, das dem angegebenen Steuerelementtext entspricht.

  10. Wenn kein übereinstimmendes Steuerelement gefunden wird, einen Fehler auslösen.
  11. Die angegebene Aktion (z. B. Klicken, Text eingeben) mit dem Puppeteer-Framework des Agenten ausführen.
  12. Screenshots des Anwendungsfensters und der ausgewählten Steuerelemente für die Protokollierung und Fehlerbehebung erfassen.
  13. Ergebnisprotokollierung:

  14. Details zur Schrittausführung protokollieren, einschließlich Steuerelementinformationen, ausgeführter Aktion und Ergebnissen.

  15. Abschluss:

  16. Den Endzustand des Anwendungsfensters speichern.

  17. Den Anwendungsclient ordnungsgemäß beenden.

Evaluierung

Der Bewertungsprozess in der Klasse ExecuteFlow dient dazu, die Leistung der ausgeführten Aufgabe anhand vordefinierter Prompts zu beurteilen.

  1. Bewertung starten:

  2. Die Bewertung beginnt unmittelbar nach der Aufgabenausführung.

  3. Dabei wird ein ExecuteEvalAgent verwendet, der während der Klassenerstellung initialisiert wird.
  4. Bewertung durchführen:

  5. Der ExecuteEvalAgent bewertet die Aufgabe anhand einer Kombination aus Eingabeaufforderungen (z. B. Hauptaufforderung und API-Aufforderung) und den während der Aufgabenausführung generierten Protokollen.

  6. Der Bewertungsprozess gibt eine Ergebnisübersicht aus (z. B. Qualitätskennzeichnung, Kommentare und Aufgabentyp).
  7. Ergebnisse protokollieren und ausgeben:

  8. Die Bewertungsergebnisse auf der Konsole anzeigen.

  9. Die Bewertungssummary zusammen mit dem ausgeführten Plan zur weiteren Analyse oder Berichterstattung zurückgeben.

Referenz

ExecuteFlow

Basisklassen: AppAgentProcessor

ExecuteFlow-Klasse zur Ausführung der Aufgabe und zum Speichern des Ergebnisses.

Die Execute-Flow-Routine für eine Aufgabe initialisieren.

Parameter
  • task_file_name (str) –

    Name der verarbeiteten Aufgabendatei.

  • context (Context) –

    Kontextobjekt für die aktuelle Sitzung.

  • environment (WindowsAppEnv) –

    Umgebungsobjekt für die verarbeitete Anwendung.

Quellcode in execution/workflow/execute_flow.py
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
def __init__(
    self, task_file_name: str, context: Context, environment: WindowsAppEnv
) -> None:
    """
    Initialize the execute flow for a task.
    :param task_file_name: Name of the task file being processed.
    :param context: Context object for the current session.
    :param environment: Environment object for the application being processed.
    """

    super().__init__(agent=ExecuteAgent, context=context)

    self.execution_time = None
    self.eval_time = None
    self._app_env = environment
    self._task_file_name = task_file_name
    self._app_name = self._app_env.app_name

    log_path = _configs["EXECUTE_LOG_PATH"].format(task=task_file_name)
    self._initialize_logs(log_path)

    self.application_window = self._app_env.find_matching_window(task_file_name)
    self.app_agent = self._get_or_create_execute_agent()
    self.eval_agent = self._get_or_create_evaluation_agent()

    self._matched_control = None  # Matched control for the current step.

execute(request, instantiated_plan)

Die Execute-Flow-Routine ausführen: Die Aufgabe ausführen und das Ergebnis speichern.

Parameter
  • request (str) –

    Die ursprüngliche Anfrage, die ausgeführt werden soll.

  • instantiated_plan (List[Dict[str, Any]]) –

    Instanziierter Plan mit auszuführenden Schritten.

Rückgabe
  • Tuple[List[Dict[str, Any]], Dict[str, str]]

    Tuple, der die Qualitätskennzeichnung der Aufgabe, einen Kommentar und den Aufgabentyp enthält.

Quellcode in execution/workflow/execute_flow.py
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
def execute(
    self, request: str, instantiated_plan: List[Dict[str, Any]]
) -> Tuple[List[Dict[str, Any]], Dict[str, str]]:
    """
    Execute the execute flow: Execute the task and save the result.
    :param request: Original request to be executed.
    :param instantiated_plan: Instantiated plan containing steps to execute.
    :return: Tuple containing task quality flag, comment, and task type.
    """

    start_time = time.time()
    try:
        executed_plan = self.execute_plan(instantiated_plan)
    except Exception as error:
        raise RuntimeError(f"Execution failed. {error}")
    finally:
        self.execution_time = round(time.time() - start_time, 3)

    start_time = time.time()
    try:
        result, _ = self.eval_agent.evaluate(
            request=request, log_path=self.log_path
        )
        utils.print_with_color(f"Result: {result}", "green")
    except Exception as error:
        raise RuntimeError(f"Evaluation failed. {error}")
    finally:
        self.eval_time = round(time.time() - start_time, 3)

    return executed_plan, result

execute_action()

Führt die Aktion aus.

Quellcode in execution/workflow/execute_flow.py
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
def execute_action(self) -> None:
    """
    Execute the action.
    """

    control_selected = None
    # Find the matching window and control.
    self.application_window = self._app_env.find_matching_window(
        self._task_file_name
    )
    if self.control_text == "":
        control_selected = self.application_window
    else:
        self._control_label, control_selected = (
            self._app_env.find_matching_controller(
                self.filtered_annotation_dict, self.control_text
            )
        )
        if control_selected:
            self._matched_control = control_selected.window_text()

    if not control_selected:
        # If the control is not found, raise an error.
        raise RuntimeError(f"Control with text '{self.control_text}' not found.")

    try:
        # Get the selected control item from the annotation dictionary and LLM response.
        # The LLM response is a number index corresponding to the key in the annotation dictionary.
        if control_selected:

            if _ufo_configs.get("SHOW_VISUAL_OUTLINE_ON_SCREEN", True):
                control_selected.draw_outline(colour="red", thickness=3)
                time.sleep(_ufo_configs.get("RECTANGLE_TIME", 0))

            control_coordinates = PhotographerDecorator.coordinate_adjusted(
                self.application_window.rectangle(), control_selected.rectangle()
            )

            self._control_log = {
                "control_class": control_selected.element_info.class_name,
                "control_type": control_selected.element_info.control_type,
                "control_automation_id": control_selected.element_info.automation_id,
                "control_friendly_class_name": control_selected.friendly_class_name(),
                "control_coordinates": {
                    "left": control_coordinates[0],
                    "top": control_coordinates[1],
                    "right": control_coordinates[2],
                    "bottom": control_coordinates[3],
                },
            }

            self.app_agent.Puppeteer.receiver_manager.create_ui_control_receiver(
                control_selected, self.application_window
            )

            # Save the screenshot of the tagged selected control.
            self.capture_control_screenshot(control_selected)

            self._results = self.app_agent.Puppeteer.execute_command(
                self._operation, self._args
            )
            self.control_reannotate = None
            if not utils.is_json_serializable(self._results):
                self._results = ""

                return

    except Exception:
        self.general_error_handler()

execute_plan(instantiated_plan)

Das ausgeführte Ergebnis vom Execute-Agenten abrufen.

Parameter
  • instantiated_plan (List[Dict[str, Any]]) –

    Plan mit auszuführenden Schritten.

Rückgabe
  • List[Dict[str, Any]]

    Liste der ausgeführten Schritte.

Quellcode in execution/workflow/execute_flow.py
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
def execute_plan(
    self, instantiated_plan: List[Dict[str, Any]]
) -> List[Dict[str, Any]]:
    """
    Get the executed result from the execute agent.
    :param instantiated_plan: Plan containing steps to execute.
    :return: List of executed steps.
    """

    # Initialize the step counter and capture the initial screenshot.
    self.session_step = 0
    try:
        time.sleep(1)
        # Initialize the API receiver
        self.app_agent.Puppeteer.receiver_manager.create_api_receiver(
            self.app_agent._app_root_name, self.app_agent._process_name
        )
        # Initialize the control receiver
        current_receiver = self.app_agent.Puppeteer.receiver_manager.receiver_list[
            -1
        ]

        if current_receiver is not None:
            self.application_window = self._app_env.find_matching_window(
                self._task_file_name
            )
            current_receiver.com_object = (
                current_receiver.get_object_from_process_name()
            )

        self.init_and_final_capture_screenshot()
    except Exception as error:
        raise RuntimeError(f"Execution initialization failed. {error}")

    # Initialize the success flag for each step.
    for index, step_plan in enumerate(instantiated_plan):
        instantiated_plan[index]["Success"] = None
        instantiated_plan[index]["MatchedControlText"] = None

    for index, step_plan in enumerate(instantiated_plan):
        try:
            self.session_step += 1

            # Check if the maximum steps have been exceeded.
            if self.session_step > _configs["MAX_STEPS"]:
                raise RuntimeError("Maximum steps exceeded.")

            self._parse_step_plan(step_plan)

            try:
                self.process()
                instantiated_plan[index]["Success"] = True
                instantiated_plan[index]["ControlLabel"] = self._control_label
                instantiated_plan[index][
                    "MatchedControlText"
                ] = self._matched_control
            except Exception as ControllerNotFoundError:
                instantiated_plan[index]["Success"] = False
                raise ControllerNotFoundError

        except Exception as error:
            err_info = RuntimeError(
                f"Step {self.session_step} execution failed. {error}"
            )
            raise err_info
    # capture the final screenshot
    self.session_step += 1
    time.sleep(1)
    self.init_and_final_capture_screenshot()
    # save the final state of the app

    win_com_receiver = None
    for receiver in reversed(
        self.app_agent.Puppeteer.receiver_manager.receiver_list
    ):
        if isinstance(receiver, WinCOMReceiverBasic):
            if receiver.client is not None:
                win_com_receiver = receiver
                break

    if win_com_receiver is not None:
        win_com_receiver.save()
        time.sleep(1)
        win_com_receiver.client.Quit()

    print("Execution complete.")

    return instantiated_plan

general_error_handler()

Allgemeine Fehler behandeln.

Quellcode in execution/workflow/execute_flow.py
374
375
376
377
378
379
def general_error_handler(self) -> None:
    """
    Handle general errors.
    """

    pass

init_and_final_capture_screenshot()

Den Screenshot erfassen.

Quellcode in execution/workflow/execute_flow.py
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
def init_and_final_capture_screenshot(self) -> None:
    """
    Capture the screenshot.
    """

    # Define the paths for the screenshots saved.
    screenshot_save_path = self.log_path + f"action_step{self.session_step}.png"

    self._memory_data.add_values_from_dict(
        {
            "CleanScreenshot": screenshot_save_path,
        }
    )

    self.photographer.capture_app_window_screenshot(
        self.application_window, save_path=screenshot_save_path
    )
    # Capture the control screenshot.
    control_selected = self._app_env.app_window
    self.capture_control_screenshot(control_selected)

log_save()

Die konstruierte Prompt-Nachricht für den PrefillAgent protokollieren.

Quellcode in execution/workflow/execute_flow.py
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
def log_save(self) -> None:
    """
    Log the constructed prompt message for the PrefillAgent.
    """

    step_memory = {
        "Step": self.session_step,
        "Subtask": self.subtask,
        "ControlLabel": self._control_label,
        "ControlText": self.control_text,
        "Action": self.action,
        "ActionType": self.app_agent.Puppeteer.get_command_types(self._operation),
        "Results": self._results,
        "Application": self.app_agent._app_root_name,
        "TimeCost": self.time_cost,
    }
    self._memory_data.add_values_from_dict(step_memory)
    self.log(self._memory_data.to_dict())

print_step_info()

Die Schrittinformationen ausgeben.

Quellcode in execution/workflow/execute_flow.py
231
232
233
234
235
236
237
238
239
240
241
242
def print_step_info(self) -> None:
    """
    Print the step information.
    """

    utils.print_with_color(
        "Step {step}: {subtask}".format(
            step=self.session_step,
            subtask=self.subtask,
        ),
        "magenta",
    )

process()

Den aktuellen Schritt verarbeiten.

Quellcode in execution/workflow/execute_flow.py
219
220
221
222
223
224
225
226
227
228
229
def process(self) -> None:
    """
    Process the current step.
    """

    step_start_time = time.time()
    self.print_step_info()
    self.capture_screenshot()
    self.execute_action()
    self.time_cost = round(time.time() - step_start_time, 3)
    self.log_save()

ExecuteAgent

Basisklassen: AppAgent

Der Agent für die Aufgabenausführung.

Den ExecuteAgent initialisieren.

Parameter
  • name (str) –

    Der Name des Agenten.

  • process_name (str) –

    Der Name des Prozesses.

  • app_root_name (str) –

    Der Name der App-Wurzel.

Quellcode in execution/agent/execute_agent.py
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
def __init__(
    self,
    name: str,
    process_name: str,
    app_root_name: str,
):
    """
    Initialize the ExecuteAgent.
    :param name: The name of the agent.
    :param process_name: The name of the process.
    :param app_root_name: The name of the app root.
    """

    self._step = 0
    self._complete = False
    self._name = name
    self._status = None
    self._process_name = process_name
    self._app_root_name = app_root_name
    self.Puppeteer = self.create_puppeteer_interface()

ExecuteEvalAgent

Basisklassen: EvaluationAgent

Der Agent zur Auswertungsbewertung der Aufgabe.

Den ExecuteEvalAgent initialisieren.

Parameter
  • name (str) –

    Der Name des Agenten.

  • app_root_name (str) –

    Der Name der App-Wurzel.

  • is_visual (bool) –

    Das Flag, das angibt, ob der Agent visuell ist oder nicht.

  • main_prompt (str) –

    Der Hauptprompt.

  • example_prompt (str) –

    Der Beispielprompt.

  • api_prompt (str) –

    Der API-Prompt.

Quellcode in execution/agent/execute_eval_agent.py
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
def __init__(
    self,
    name: str,
    app_root_name: str,
    is_visual: bool,
    main_prompt: str,
    example_prompt: str,
    api_prompt: str,
):
    """
    Initialize the ExecuteEvalAgent.
    :param name: The name of the agent.
    :param app_root_name: The name of the app root.
    :param is_visual: The flag indicating whether the agent is visual or not.
    :param main_prompt: The main prompt.
    :param example_prompt: The example prompt.
    :param api_prompt: The API prompt.
    """

    super().__init__(
        name=name,
        app_root_name=app_root_name,
        is_visual=is_visual,
        main_prompt=main_prompt,
        example_prompt=example_prompt,
        api_prompt=api_prompt,
    )

get_prompter(is_visual, prompt_template, example_prompt_template, api_prompt_template, root_name=None)

Den Prompter für den Agenten abrufen.

Parameter
  • is_visual (bool) –

    Das Flag, das angibt, ob der Agent visuell ist oder nicht.

  • prompt_template (str) –

    Die Prompt-Vorlage.

  • example_prompt_template (str) –

    Die Beispiel-Prompt-Vorlage.

  • api_prompt_template (str) –

    Die API-Prompt-Vorlage.

  • root_name (Optional[str], Standard: None ) –

    Der Name der Wurzel.

Rückgabe
  • ExecuteEvalAgentPrompter

    Der Prompter.

Quellcode in execution/agent/execute_eval_agent.py
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
def get_prompter(
    self,
    is_visual: bool,
    prompt_template: str,
    example_prompt_template: str,
    api_prompt_template: str,
    root_name: Optional[str] = None,
) -> ExecuteEvalAgentPrompter:
    """
    Get the prompter for the agent.
    :param is_visual: The flag indicating whether the agent is visual or not.
    :param prompt_template: The prompt template.
    :param example_prompt_template: The example prompt template.
    :param api_prompt_template: The API prompt template.
    :param root_name: The name of the root.
    :return: The prompter.
    """

    return ExecuteEvalAgentPrompter(
        is_visual=is_visual,
        prompt_template=prompt_template,
        example_prompt_template=example_prompt_template,
        api_prompt_template=api_prompt_template,
        root_name=root_name,
    )
